Tape Rewinding Machine
Apply to rewinding medical tape jumbo rolls into required length.
1. Two section length setting, accurate winding length, it stops automatically with inverter control when the setting length is reached.
2. High-performance programmable controller making overall rewinding operation quite easily. Length counting and tension control are via LED touch screen.
3. Pneumatic paper tube securing design, with robust paper tube easy and quick for loading and unloading, promoting efficiency to the most.
4. Automatic tailing paper smoothening device, to eliminate wrinkling or air bubbles after rewinding, ensuring the rewound products neat and smooth.
5. Hydraulic loading mechanism(optional) ensuring easy and simple material loading operations.
| Machine Width | 1.0M 1.3M |
| Rewinding Width | 960-1200mm |
| Max Unwinding Diameter | 800mm |
| Max Rewinding Diameter | 25.4-120mm |
| Max Rewinding Speed | 130M/min |
| Paper Tube ID | Φ25.4、38mm |
| Main Motor | 5HP×2 |
| Adopted Air Pressure | 6bar |
UNWINDING PART
Jumbo roll is held on the pneumatic shaft, easy and fast to load and unload.
SEPARATE LINER FILM REWINDING UNIT
Separate rewinding shaft to rewind release film of medical tape jumbo roll.
LENGTH COUNTER
Three section meter counter to make sure the accurate of there winding length.
REWINDING SYSTEMWITH SHAFTLESS
Smoothing roller press the tape with 1" core , more fast and stable during rewinding
